F200Bi/F400Bi/F600Bi

F200Bi/F400Bi/F600Bi

KNOWLED Flexible LED mat
Watch Video

Watch Video
Foldable & Durable

The KNOWLED Flexible LED Mat boasts a unique foldable design, allowing it to be effortlessly folded along pre-set lines. This feature not only protects the LED beads, ensuring exceptional durability and reliable lighting, but also enables easy storage and portability.

IP65 Water-Resistance

With an IP65 water-resistant rating, the KNOWLED Flexible LED Mat is capable of withstanding water spray from any angle, and performs well in outdoor shooting environments, even in rainy weather, making it superior to ordinary LED mats in terms of water resistance.

(*The control box is not waterproof.)

Flexible Lighting Setup

The KNOWLED flexible LED mat is an ideal solution for illuminating low-ceilinged rooms, narrow spaces like kitchens, or even inside a car. With hanging rings and hook-and-loop fasteners, securing the light is effortless, whether you hang or stick it. Connect multiple lights for personalized lighting arrangements that suit your specific needs. This provides great convenience for on-set lighting work.

Cinema-Grade Lighting Performance

With a flicker-free frame rate of 120fps and a CRI and TLCI rating of 96+, the KNOWLED Flexible LED Mat delivers accurate color reproduction. Paired with a softbox and grid, its precise white light creates fine shadows, bringing your characters to life on the big screen with exceptional detail.

3 Sizes, Flexible Lighting

Available in three different sizes, each suitable for different use cases. Additionally, with the capability to seamlessly connect multiple pads, you can customize your lighting settings to meet the lighting needs of any space.

Multiple Ways
to Control

In addition to the control box, the KNOWLED Flexible LED Mat can be controlled through DMX (supporting RDM protocol), 2.4G wireless control, and the upgraded Godox Light APP version 3.0. With the Godox TimoLink RX, this light also supports CRMX control.

Enhanced Powering

It has 48V DC input that supports power supply from an external power stations. And the upgraded Type-A interface can be used to upgrade the firmware of the fixture, as well as to power the wireless DMX receiver for continuous on-set operation.

Uncompromised Power

With a CCT range from 2700K to 8500K, you can easily simulate the look of natural sunlight or moonlight. And its uncompromising power output in any color temperature ensures reliable illuminating performance for all your filming needs.

Built Tough
to Withstand On-Set Rough

The KNOWLED Flexible LED Mat is robustly built to withstand even the most challenging conditions. Its high-quality aluminum alloy X-frame ensures superior durability and sturdiness. With an ideal balance of weight, brightness, durability, and performance, this light is the perfect choice for any filming application.

Tech Specs
ModelF200BiF400BiF600Bi
Power Supply100V-240V~50/60Hz 2.1A100V-240V~50/60Hz  4.1A100V-240V~50/60Hz   6.7A
Max. Power≈210W≈410W≈670W
CCT2700-8500K
Brightness Range0%-100%
Dimming Curveslinear, s-curve, exponential, logarithmic
FX  Modes11
CRIAverage ≥96
TLClAverage≥96
Waterproof Grade of Light BodyIP65
Controlling MethodsDMX 512 Control (support RDM protocol)/ 2.4GHz Wireless Control/ Bluetooth APP Control
Bluetooth Controlling DistanceMax. 30m
2.4G Remote Control DistanceMax. 60m
Type-A USB PortFirmware Upgrade/5V⎓1A Power SupplyFirmware Upgrade/5V⎓1A Power SupplyFirmware Upgrade/5V⎓1A Power Supply
DimensionLight Body: 650mm*631mm*29mm

(excluding DC cable)

Controller: 124mm*132mm*270mm

Light Body: 1209mm*627mm*23mm

(excluding DC cable)

Controller:124mm*132mm*270mm

Light Body: 1210mm*1210mm*24mm

(excluding DC cable)

Controller:179mm*123mm*332mm

Netweight≈

Light Body: 1.83kg

(including X bracket and adapter)

Controller: 2.77kg

Light Body: 3.1kg

(including X bracket)

Controller: 3.07kg

Light Body: 3.8Kg

Controller: 3.9Kg




Lux Data


F200BiCCTUnit1m2m3m
2700Klux66801910915
fc62017785
3200Klux734021001000
fc68219593
4300Klux807023001100
fc750214103
5600Klux830023701130
fc770220105
6500Klux816023401110
fc758217103
8500Klux770022101050
fc71420698




F400BiCCTUnit1m2m3m
2700Klux1150035501760
fc1070330164
3200Klux1260039201940
fc1170364180
4300Klux1420044402190
fc1320412204
5600Klux1470046102280
fc1370428212
6500Klux1430045202230
fc1330419207
8500Klux1380043302130
fc1280402198




F600Bi
CCTUnit1m2m3m5m
2700Klux≈16300≈5640≈2670≈1060
fc≈1510≈524≈248≈98.9
3200Klux≈17400≈6020≈2860≈1130
fc≈1620≈559≈265≈105
4300Klux≈19200≈6620≈3130≈1240
fc≈1790≈615≈291≈115
5600Klux≈19900≈6830≈3240≈1280
fc≈1850≈635≈301≈119
6500Klux≈19700≈6740≈3200≈1270
fc≈1830≈626≈297≈118
8500Klux≈18800≈6440≈3050≈1210
fc≈1750≈598≈283≈113


Downloads
Product Manual
